Educational Automotive Electrical System Demonstration Board

Name: Educational Automotive Electrical System Demonstration Board
Brand: Guangdong Zhongcai Education Equipment Co., Ltd.
SKU: ZC-QCD16H
Availability: InStock

Brand Name:	Zhongcai
Model Number:	ZC-QCD16H
MOQ:	1
Price:	Negotiatable
Delivery Time:	15-25Work Days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong,China

Certification:

IS09001/CE

Language:

Customized

Warranty:

1 Year

Power Source:

Electricity

Color:

Customized

Safety Protection:

Multiple Safety Protection Measures

Voltage:

AC 220V

Mobile Caster:

120 X 80mm

Training Level:

Basic And Advanced

Packaging Details:

Wooden Box

Supply Ability:

1000

Highlight:

Electrical System Demonstration Board

Automotive Electrical System Demonstration Board

Educational Automotive Electrical System Demonstration

Product Description

Product Overview

This Automotive Demonstration Board is constructed using genuine electrical components from the Toyota Land Cruiser, integrating 10 core systems including ignition system, instrument cluster, lighting system, and wiper system. As an advanced Electrical System Training Platform, its modular design combines theoretical education with hands-on practice, making it ideal for vocational institutes and training centers offering automotive electrical diagnostics and repair programs.

Technical Specifications & Features

Category	Specifications	Functional Highlights
Basic Params	Dimensions: 2400×600×1800mm	Unified structure fits standard training spaces
	Operating Voltage: DC 12V	Matches real-vehicle voltage environment (Key Feature)
	Temperature Range: -40℃～50℃	Supports extreme-condition training
Power Module	Motor Type: Single-phase async	Simulates actual load conditions
	Rated Voltage: AC 220V	Industrial-grade power supply
	Rated Power: 2.2KW	Stable multi-system operation
	Rated Speed: 1400r/min	Precise mechanical motion replication
Structure	Frame: 40403mm steel tube	High-rigidity anti-deformation design
	Cabinet: 1.5mm cold-rolled steel	Impact/corrosion resistant
	Mobility: 100*50mm casters	Lockable wheels for lab flexibility

Key Advantages:

Military-grade Durability: -40℃ cold-start capability for intensive training
OEM Data Compatibility: Supports OBD-II protocols for factory data stream analysis
Safety Assurance: Dual protection with overload circuits + emergency stop

Educational Automotive Electrical System Demonstration Board 0

Educational Automotive Electrical System Demonstration Board 1

Educational Automotive Electrical System Demonstration Board 2

Educational Automotive Electrical System Demonstration Board 3

Educational Automotive Electrical System Demonstration Board 4

Educational Automotive Electrical System Demonstration Board 5

Educational Automotive Electrical System Demonstration Board 6
