1. Product Overview

The NEV Electrical System Training Platform is an integrated diagnostic station designed to pair with the NEV Chassis System Training Platform. Utilizing MIL-STD aviation connectors, it provides direct access to low-voltage circuits for real-time measurement and analysis of critical EV subsystems, including:
• Battery Management System (BMS) & Charging Networks
• High-Voltage Distribution Unit (PDU)
• Climate Control & Thermal Management
• Body Electronics (Lighting, Wipers, Access Controls)

2. Core Technical Advantages

A. Precision Diagnostics

• Aviation-grade interfaces ensure signal integrity for measuring voltage/current waveforms, CAN bus traffic, and insulation resistance.
• Color-coded test points align with schematic diagrams for rapid fault isolation.

B. Industrial-Grade Construction

• 3mm reinforced aluminum composite panels with chemical-resistant silkscreen printing.
• Ergonomic steel frame (450mm work surface) with ESD-safe coating and dual-brake casters.

C. Smart Training Integration

• Compatible with OEM diagnostic tools for authentic workshop workflows.
• Supports open/short circuit injection for failure mode analysis.

3. Pedagogical Value Proposition

Scenario-Based Learning

• Emulates 12+ real-world failure cases in BMS communication, charging handshakes, and HVAC control logic.

Cross-Disciplinary Skill Development

• Bridges high-voltage safety protocols with low-voltage system diagnostics.
• Reinforces systems thinking through chassis-electrical correlation exercises.

Certification Alignment

• Meets IMI/EATA L2/L3 competency requirements for NEV maintenance technicians.

Whole Product

FAQ

Q1: Are you a trading company or manufacturer?
We are a manufacturer, our equipment is superior in quality and reasonable in price.

Q2: May we visit your factory?
Yes, welcome to our factory, our factory is in China Guangzhou City, it is near the Guangzhou Baiyun airport, very convenient to come here.

Q3: How to ensure the quality?
Our technicians are experts in this industry.Each assembly part has a controller to ensure stable operation of the equipment.

Q4: What is the warranty period and the delivery period?
Warranty period:12 months Delivery period: Usually 30 days

Q5: What is you terms of payment?
50% in advance, balance before shipment, we accept T/T, Cash.
